Appendix 31
02/24/2010 175-253M
Appendix
New Parts
New Parts: Main Kits
175-248A 800 FERT 6 FLD INST ON SGS
175-249A 800 FERT 6 FLD INST WITH DRIVE 175-250A 800 FERT 7.5 FLD INST ON SGS
175-251A 800 FERT 7.5 FLD INST WITH DRV
Callout
Quantity in Kit 175-
Part
Number Description Remarks
-248A -249A -250A -251A
1 1 1 1 175-253M MANUAL 800 EW FERT FLD INST this manual
1 1 123-832H SLOTTED IDLER ARM 1/2 X 3 5/16 pre-installed
15 12 133-325L SGS OPENER SIDE DELIVERY BDL see page 32 for breakdown
1 1 136-014D CHAIN RL #40 79 PITCHES
1 1 1 1 136-153D CHAIN RL #40 55 PITCHES pre-installed
1 1 1 1 136-250D CHAIN RL #40 96 PITCHES
2 2 2 141-116H FERTILIZER LATCH WELDMENT pre-installed
2 2 2 142-009D COVER HANDLE CHAIN pre-installed
1 1 142-064D RH WLK BRD SUPP FERT
1 1 142-077D LH WLK BRD SUPP FERT
15 15 12 12 142-257L FERT TUBE AND HDWR BDL see page 32 for breakdown
1 1 142-264K 8FT EW FERT TRAY ASY 6 see page 32 for breakdown
1 1 1 1 142-266L FERT. BOX & LID ASY see page 34 for breakdown
1 1 142-267K 8FT EW FERT TRAY ASY 7 1/2 see page 32 for breakdown
2 2 2 142-273D FERT TRAY LATCH STRIKE pre-installed
1 1 142-298D RH WLK BRD SUPP SML SDS-FERT
1 1 142-312D LH WLK BRD SUPP SML SDS-FERT
1 1 168-127D 3/16 X 1 KEY pre-installed
1 1 175-266K 8FT EW AUX JACKSHAFT ASY see page 35 for breakdown
8 6 8 6 802-034C HHCS 1/2-13X1 1/4 GR5
18 18 18 18 802-148C HFSS 1/4-20X1/2 GR5
1 2 1 2 802-214C RHSNB 1/2-13X1 1/4 GR5
8 8 8 8 803-020C NUT HEX 1/2-13 PLT
18 18 18 18 803-088C NUT HEX LOCK 1/4-20 FLG pre-installed
1 1 803-169C NUT HEX FLG. LOCK 1/2-13 PLT.
8 8 8 8 804-015C WASHER LOCK SPRING 1/2 PLT
1 1 804-016C WASHER FLAT 1/2 SAE PLT pre-installed
4 4 4 805-019C PIN COTTER 5/32 X 1 PLT pre-installed
1 1 805-067C PIN COTTER 1/8 X 3/4 pre-installed
1 1 808-170C SPKT 40B17 X 3/4BORE W/KW&SS pre-installed
1 1 817-025C NO. 40 12T IDLER SPKT. pre-installed
2 2 2 2 838-265C DECAL REFLECTOR AMBER 1 1/2X9
1 1 1 1 848-276C DECAL 800 pre-installed
100
106
109
110
112
113
117
118
119
120
124
132
135
136
137
138
139
146
148
172
176
178
191
193
195
204
205
209
211
220
226
238
239
