TSF660
500-644M 9/1/2009
50
Pumps
The standard TSF660 does not include a pump. Optional
hydraulic pump is available.
Ace Hydraulic Pump
If ordered with a new TSF660 (Option 35), the pump is
pre-installed prior to delivery.
For operation, see “Hydraulic Driven Pumps” on
page 21.
Pump kit weight: 40 lbs (18 kg)
Ace Flow Limiter
On tractors with LOAD SENSING (LS) Closed Center hy-
draulic systems, this device limits the flow of oil to the Ace
motor and prevents failures due to misapplication. Your
Great Plains dealer can assist with installation of the flow
limiter.
For use, see “Ace Pump Flow Limiter (Option)” on page
17.
Description Option
Part
Numbers
PUMP - TS HIGH VOL HYD 35 507-106A
Description
Part
Numbers
FLOW LIMITER VALVE - ACE PUMP 829-125C (2006-)
FLOW LIMITER VALVE - ACE PUMP 829-131C (2007+)
Figure 27
Hydraulic Pump Components
27301
Figure 28
Ace Flow Limiter
23395
