83
Installing and Upgrading Internal Components in Cisco 3800 Series Routers
OL-5975-04
Component Locations on the Motherboard
Figure 50 Removing the Motherboard from a Cisco 3845 Router
To install or replace SDRAM DIMMs, AIMs, or PVDMs on the motherboard, continue with the
“Component Locations on the Motherboard” section on page 83 .
Component Locations on the Motherboard
Figure 51 and Figure 52 show the locations of SDRAM DIMMs, AIMs, and PVDMs on the motherboard
of Cisco 3825 and Cisco 3845 routers.
1 Loosen captive thumbscrews 2 Rotate ejector levers outward
117938
2
1
1 2
