7-16
Quick fixed automation series torches
SM-QFTORCH REPLACEMENT PARTS
QFW Series Replacement Parts
Item No. Part No. Stock No. Description
1 --- --- Cartrdge Kt - (Includes Item #2, #3 and Hose Clamps)
QRWA-1BC 3045-1288 For use wth 1-5/8” (41,28mm) Ø Mount – QRWA Seres - ***
NS QR106RLS 3045-1341 Replacement Lockng Set Screw F/Torch Block (Pkg. of 5 ea.)
2 --- --- Key
QTRMS-BS 3045-1156 For use wth QRA-1BC (Pkg. Of 5 ea.)
3 QR106-S 3045-1158 Condut Screw (Pkg. Of 5 ea.)
4 QR-FC 3045-1161 Front case (Includes Item “B”)
5 QRW-CV 3045-1304 Check Valve Assembly (Includes O-rngs)
6 --- --- QFW Power Cable Assy (Includes Hose Clamp)
QR404-CH 3045-1252 For use wth 4ft. ( 1,22m) torch
QR406-CH 3045-1256 For use wth 6ft. (1,83m) torch
QR408-CH 3045-1258 For use wth 8ft. (2,44m) torch
QR410-CH 3045-1259 For use wth 10ft. (3m) torch
QR412-CH 3045-1260 For use wth 12ft. (4m) torch
QR415-CH 3045-1261 For use wth 15ft. (5m) torch
7 --- --- Front Sprng
QR-SPR 3045-1177 For use wth 4ft. (1,22m) through 7ft. (2.13m) torches
QR-SPHD 3045-1178 For use wth 8ft. (2,44m) through 15ft. (5m) torches
8 --- --- Rear Sprng
QR-SPHD 3045-1178 For use wth 4ft. (1,22m) through 15ft. (5m) torches
9 --- --- Purge Hose Assembly (Includes Hose Npple Plug & Hose Clamp)
QR04-PH 3045-1202 For use wth 4ft. ( 1,22m) torch
QR06-PH 3045-1206 For use wth 6ft. (1,83m) torch
QR08-PH 3045-1208 For use wth 8ft. (2,44m) torch
QR10-PH 3045-1209 For use wth 10ft. (3m) torch
QR12-PH 3045-1210 For use wth 12ft. (4m) torch
QR15-PH 3045-1211 For use wth 15ft. (5m) torch
10 --- --- Water-Out Hose Assembly (Includes Hose Clamp)
QRW04-WO 3045-1265 For use wth 4ft. ( 1,22m) torch
QRW06-WO 3045-1269 For use wth 6ft. (1,83m) torch
QRW08-WO 3045-1271 For use wth 8ft. (2,44m) torch
QRW10-WO 3045-1272 For use wth 10ft. (3m) torch
QRW12-WO 3045-1273 For use wth 12ft. (4m) torch
QRW15-WO 3045-1274 For use wth 15ft. (5m) torch
11 --- --- Water-In Hose Assembly (Includes Hose Clamps)
QRW04-WI 3045-1277 For use wth 4ft. ( 1,22m) torch
QRW06-WI 3045-1281 For use wth 6ft. (1,83m) torch
QRW08-WI 3045-1283 For use wth 8ft. (2,44m) torch
QRW10-WI 3045-1284 For use wth 10ft. (3m) torch
QRW12-WI 3045-1285 For use wth 12ft. (4m) torch
QRW15-WI 3045-1286 For use wth 15ft. (5m) torch
*** Standard on all QFW Seres Torch Body and Cable Assembles
