7-14
Quick fixed automation series torches
SM-QFTORCH REPLACEMENT PARTS
Item No. Part No. Stock No. Descrpton
12 QRA-CS 3045-1239 Rear Case Assembly
13 R176MH 2060-2184 Mller ® Connector Plug (Includes Items #16 & 17) - ***
R174MH 2035-2109 Mller ® Connector Plug (Includes Items #16 & #17)
14 R175M-N045 2050-2181 Mller ® Plug Npple, .045” (1,0mm) Wre (use w/R176MH) - ***
R174M-N045 2040-2192 Mller ® Plug Npple, .045” (1,0mm) Wre (use w/R174MH)
15 R175M-N116 2050-2182 Mller ® Plug Npple, .062” (1,6mm) Wre (use w/R176MH) - ***
R174M-N116 2040-2191 Mller ® Plug Npple, .062” (1,6mm) Wre (use w/R174MH)
16 176S-H 2060-2177 Tweco ® Connector Plug - ***
350-174H 2035-2110 Tweco ® Connector Plug (uses R44 seres Condut)
17 350-174PH 2035-2172 Panasonc ® Connector Plug (uses R44 seres Condut )
18 QTR176LH 2086-2624 Lncoln ® Connector Plug (2.71” – 68,83mm OAL.) - ***
EL176LH 2060-2680 Lncoln ® Connector Plug (3.84” – 97,54mm OAL)
QTR174LH 2086-2623 Lncoln ® Connector Plug (uses R44 seres Condut)
19 --- --- Condut (Refer to Page 18)
20 QTR-TOOLS 2062-2034 Tool Kt
Standard Fasteners
These standard fasteners are not sellable tems and must be purchased at a local hardware or fastener supply house.
Item No. Description
A #10-32 x 3/16” Stanless Cup Pont Set Screw
QFA Series Replacement Parts (cont.)
*** Standard on all QFA Seres Torch Body and Cable Assembles
