WeldSkill Auto-Darkening Welding Helmets
February 29, 2012
11
SECTION 5: Specifications
5.01
WeldSkill Auto-Darkening Filter Lens
Description
(Refer Note 1)
Fixed Shade 11 (454304)
Variable Shade 9-13
(454305, 454314, 454321, 454322,
454323 & 454324)
Auto-Darkening Filter Lens Part
Number
454306
(Note: Fixed Shade 11 Auto-Darkening Lens
Part Number 454306 is fitted to the WeldSkill
Auto-Darkening Welding Helmet Product Part
Number: 454304).
454307
(Note: Variable Shade 9-13 Auto-Darkening Lens Part
Number 454307 is fitted to the WeldSkill Auto-Darkening
Welding Helmet Product Part Number: 454305, 454314,
454321, 454322, 454323 and 454324).
Filter Lens Dimensions
110mm x 90mm x 9mm
110mm x 90mm x 9mm
Viewing Area Dimensions
98mm x 43mm
98mm x 43mm
Reaction Time
1/30,000 second
1/30,000 second
Sensors
2 Optical Sensors
2 Optical Sensors
Power Supply
Solar Cells, No Battery change
required
Solar Cells, No Battery change required
Unactivated Shade Level
4
4
Variable Shade Level
Not Fitted (Fixed Shade 11)
9 - 13
Operating Temperature
-5
0
C to
+ 55
0
C
-5
0
C to
+ 55
0
C
Storing Temperature
-20
0
C
to
+70
0
C
-20
0
C
to
+70
0
C
Sensitivity Range (Light to Dark)
Low to High
Low to High
Delay (Dark to Light)
Short (0.25 sec) – Long (0.6 sec)
Min (0.25 sec) – Max (0.8 sec)
On/Off Control
Automatic
Automatic
Weight
110g
124g
Note:
Due to variations that can occur in manufactured products, claimed performance, voltages, ratings, all capacities,
measurements, dimensions and weights quoted are approximate only. Achievable capacities and ratings in use and
operation will depend upon correct installation, use, applications, maintenance and service.
5.02
Contents
CONTENTS
- WELDSKILL WELDING HELMET
Description
Quantity
WeldSkill Auto-Darkening Welding Helmet
1
Front Cover Lens
1
Rear Cover Lens
1
Operating Manual
1
