TRANSMIG VAF4HD
Manual 0-5269 2-3 INTRODUCTION
2.08 Specifications
Description Transmig VAF4HD Wirefeeder
Wirefeeder Part Number W3000701
Wirefeeder Dimensions H 255mm x W 460mm x D 755mm
Wirefeeder Mass 21.5kg
Input Voltage 42VAC or 115VAC, 350VA
Input Voltage Tolerance ±15%
Input Frequency 50/60 Hz
Gas Solenoid Voltage 24vdc
Maximum Gas Pressure 0.7 Mpa (7 bar)
MIG Welding Output, 40°C, 10
min
550A at 60%
450A at 100%
Minimum Wire Feed Speed 1.2 - 1.5 MPM (47 - 59 IPM)
Maximum Wire Feed Speed 16.0 - 17.5 MPM (630 - 689 IPM)
Operating Temperature Range 0°C - 40°C
Interconnection Plug 19pin
Wire Sizes
Solid 0.9mm (0.035”) to 1.6mm (1/16”)
Aluminium 1.0mm (0.035”) to 1.6mm (1/16”)
Flux Cored 1.2mm (0.045”) to 3.2mm (1/8”)
Maximum Wire Spool Weight 60 lb./ 27kg
Table 2-1 Transmig VAF4HD Specification
NOTE
Due to variations that can occur in manufactured products, claimed performance, voltages, ratings, all capacities,
measurements, dimensions and weights quoted are approximate only. Achievable capacities and ratings in use
and operation will depend upon correct installation, use, applications, maintenance and service.
In the interest of continuous improvement, CIGWELD Pty. Ltd. reserves the right to change the specifications or
design of any of its products without prior notice.
2.09 Optional Accessories
Feed Rolls
Wire Size Wire Type Part Number
0.9 mm/ 1.2 mm* Hard W4017000
1.2mm/ 1.6 mm Hard W4017001
0.9mm/ 1.0 mm Soft W4017100
1.2mm/ 1.6 mm Soft W4017101
2.0mm/ 2.4 mm Soft W4017102
0.9 mm & 1.2 mm Cored W4017200
1.2mm/ 1.6 mm Cored W4017201
2.0mm/ 2.4 mm Cored W4017202
2.8mm Cored W4017203
3.2mm Cored W4017204
Table 2-2 Feed Rolls
NOTE
Two feed rolls are required for each wire size.
NOTE
* indicates fitted as standard.
