30
9.3 WC 1 Pendant Enclosure P/N: C3A5006
ITEM QTY PART NO DESCRIPTION
1 1 C3A5007 WC 1 Pendant Base
2 1 C3E5008 WC 1 Pendant Cover
3 2 X3S5125 Switch, Black Pushbutton SPDT Idec #AB6M-M1-B
4 1 X3S5126 Switch, Selector SPDT Idec #AS6M-2Y2P
5 1 X3S5128 Switch, Pushbutton Red SPDT Idec #AB6M-V1-R
6 2 X5D5052 LED, Green Imlec #LED-407G
7 1 X5D5053 LED, Red Imlec #LED-407R
8 2 X6A5014 Handle, Black 3” Center RAF #8047-440-A-24
9 1 X3P5793 Strip, Terminal 12 Circuit Molex #C1512-151
10 1 X3Z5006 Fitting, Black Pigtail Heyco #3240
11 25’ X3W5097 Cable, 8 Cond. 26awg Shielded Belden #1213A
12 1 X3P5142 Connector, Plug Housing 9 pin CPC Amp #206708-1
13 9 X3P0303 Socket, Crimp 20-24 Gauge Amp #66105-2
14 1 X3Z5060 Clamp, Cable CPC Amp #206966-1
15 4 X6Z5090 Bumper, Black Self-Adhesive HH Smith #2446-103
16 3 X5R0051 Resistor, 2.7K ohm 5% 1/2W #RL20S272G
17 2 #2-56 X 5/8" Long Pan Head Screw
18 2 #2 Internal Lock Washer
19 2 #2-56 Hex Nut
20 4 #4-40 X 1/4" Long Pan Head Screw w/ Internal Lock Washer
21 4 #6-32 X 1/4" Long Pan Head Screw w/ Internal Lock Washer
