17
6.8 Setup Parameter Menus
The WC 1 controller can support several different options. The setup Parameter menu allows the
user to configure various setup control parameters and options. Depending on which options are
enabled different Weld parameter menus will be displayed. The user can also specify the current
range for a power supply and enable remote I/O weld schedule selections.
6.9 Setup Parameter Menu Screens
DISPLAY PARAMETER DESCRIPTION RANGE UNITS
REMOTE SCHEDULE
SELECT = Enable remote weld schedule option. When “ON” the
user supplied I/O SCHED 0 - 4 inputs (TB5-6- TB5-10) will
specify the desired weld schedule. Refer to Section 4.5
for additional information ON/OFF
GTAW CONTROL
MODE = Enables the GTAW process mode and weld parameter
menus ON/OFF
GMAW CONTROL
MODE = Enables the WC 1 control for the GMAW (MIG/MAG)
process mode and weld parameter menu ON/OFF
MAX CURRENT
AMP = The Maximum current level that the power source can
provide. This value is used to scale the WC 1 analog
output. 1- 500 Amps
MIN CURRENT
AMP = The Minimum current level that the power source can
provide. This value is used to scale the WC 1 analog
output. 1- 500 Amps
Table 6- Setup Parameter menu functions
