27
9.2 WC 1 Control Enclosure – Capstan Motor Drive Layout P/N: C3A5004
ITEM QTY PART NO DESCRIPTION
1 1 C3A5003 WC 1 Control Enclosure
2 1 C3E5004 WC 1 Control Cover
3 1 C3E5005 WC 1 Control Front Overlay
4 1 C5A5003-WC Weld Control PCB Assembly
5 1 C5A5004-WC Universal Pendant PCB Assembly
6 1 S3A5031 2 x 16 LCD Display Assembly
7 1 S2M5087 2 x 16 LCD Display Lens
8 1 C3W5002 WC 1 Control Wire Harness
9 1 C3W5003 WC 1 Front Panel Wire Harness
10 1 C3W5004 WC 1 Power Cord
11 1 C3W5005 WC 1 Power Switch Wire Harness
12 1 C3W5006 PWM Control Wire Harness
13 1 C3W5007 PWM AC Power Wire Harness
14 1 C3W5008 PWM DC Power Wire Harness
15 1 C3W5009 PWM Motor Drive Cable
16 1 C3W5010 PWM Toroidal Transformer
17 1 S2M5050 Microstep Heatsink
18 1 C5A5005 PWM Driver PCB Assembly
19 1 C5A5006-9CM PWM 9CM CPU PCB Assembly
20 1 C5A5007 PWM Power Supply PCB Assembly
21 7 X6S5023 Spacer, #6-32 x 1/2” Long SS M-F RAF #4534-632-SS-0
22 4 X6S5057 Spacer, #6-32 x 1/4” Long SS M-F RAF #4530-632-SS-0
23 1 X3C5026 Fuse, 8 amp 3ag Littlefuse #313008
24 4 X6S5050 Spacer, #2 x 7/16” Long Nylon HH Smith #9165
25 4 X6S5056 Spacer, #2-56 x ¾” Long Stainless Steel RAF #2061-256-SS
26 1 X3S5078 Switch, Power Rocker Cutler-Hammer #1600R11E
27 3 X3S5125 Switch, Black Pushbutton SPDT Idec #AB6M-M1-B
28 1 X3S5127 Switch, Keylock SPDT Idec #AS6M-2KT2PB
29 1 X3Z5027 Kit, Screwlock Std. Female Amp #205817-3
30 2 X3Z5006 Fitting, Black Pigtail Heyco #3240
31 4 X6Z5036 Bumper, Black HH Smith #2135
32 1 X6Z5069 Plug, Dome Hole Black 7/8" Heyco #2703
33 4 X5Z5007 Washer, Shoulder Thermalloy #7721-7PPS
34 3” Tape, Kapton 1” Wide
35 A/R Compound, Thermal Thermalloy #249
36 8 #2 Internal Lock Washer
37 4 #2-56 Hex Nut
38 4 #2-56 X 1/4" Long Pan Head Screw
39 4 #4-40 x 1/4” Long Pan Head Screw
40 18 #6-32 X 1/4" Long Pan Head Screw w/ Internal Lock Washer
41 8 #6-32 X 1/2" Long Pan Head Screw
42 8 #6 Internal Lock Washer
43 9 #6-32 Hex Nut
44 4 #6-32 X 3/8" Long Socket Cap Head Screw
45 4 #10-32 X 1/2" Long Pan Head Screw
46 1 #10-32 X 7/8" Long Pan Head Screw
47 1 #10 External Lock Washer
