THERMAL ARC 201 Ts APPENDIX
Appendix A-2 Manual 0-5149
APPENDIX 2: REPLACEMENT PARTS
Item
No
Description Part No. Reference Designator
1 Handle W7003040
2 Panel, Cover W7003200
3 Rectifier 1000V,50A W7003010
4 PCB, Control, 201 TS W7003222 PCB2
5 Thermostat W7003016 THC1, THC2
6 Resistor,4 ohm,60W W7003055 R1
7 PCB, Power, 201 TS W7003216 PCB1
8 Insulation Sheet W7003214
9 Points, HF Starter, 201 TS W7003034
10 Output Inductor Ferrite Core W7003210
11 Front Control PCB3 W7003218 PCB3
12 Front Panel W7003205
13 Front Panel Label W7003219
14 Rubber Boot W7003064
15 Knob, control, Red, 21 ODx6 ID W7003079
16 Connector, Gas Outlet, 161 STL-201
TS
W7003212
17 Output Terminal, 50mm dinse W7003020
18 Socket, 8 Pin, cable, 161 STL-201 TS W7003220
19 Gas Solenoid W7003033
20 Current Sensor, 161-201TS W7003076 Current Sensor
21 Base Panel W7003209
22 Fan,24V DC W7003090
23 Rear Panel W7003201
24 Connector, Gas Inlet, 161 STL-201 TS W7003215
25 ON/OFF Switch W7003053 SW1
26 PCB, Remote, 161 STL-201 TS W7003221 PCB4
WARNING
There are extremely dangerous voltages and power levels present inside this product. Do not attempt
to repair unless you are an Accredited Thermal Arc Service Agent and you have had training in power
measurements and troubleshooting techniques. If major complex subassemblies are faulty, then the
Welding Power Source must be returned to an Accredited Thermal Arc Service Agent for repair.
