Manual 0-5149 2-5 Introduction
INTRODUCTION THERMAL ARC 201 TS
2.09 Specifications
Power Source Part Number W1003802
Mains Power
Nominal Supply Voltage AC 110V AC 230V
Number of Phases Single Phase Single Phase
Input Voltage Range AC 104- 127V AC 187- 253V
Nominal Supply Frequency 50/60 Hz 50/60 Hz
Effective Input Current (l1eff) 20 Amps 16 Amps
Maximum Input Current (l1 max) ∆ 39 Amps ∆ 32 Amps
Single Phase Generator Requirements
[Continuous rating at nominal supply voltage
with maximum output for STICK (MMA) welding]
5 KVA 8 KVA
Welding Output
Welding Current Range Stick: 10 - 125 Amps
TIG: 10 - 160 Amps
Stick/TIG:
10 - 200 Amps
Nominal DC Open Circuit Voltage (OCV) 71V 71V
Welding Output, 104º F (40º C), 10 min.
(Quoted figures refer to STICK (MMA) output)
125A @ 25%, 25.0V
95A @ 60%, 23.8V
80A @ 100%, 23 .2V
200A @ 20%, 28V
120A @ 60%, 24.8V
100A @ 100%, 24.0V
Rated Input Current (A) 39A 32A
for STICK (MMA) Welding Io = 125A @ 25.0V Io = 200A @ 28V
Rated Input Current (A) 30A 20.6A
for LIFT TIG/HF TIG (GTAW) Welding Io = 160A @ 16.4V Io = 200A @ 18V
Rated Output for STICK (MMA) Welding 25.0V, 125A @ 25% 28V, 200A @ 20%
Rated Output for LIFT TIG/HF TIG (GTAW)
Welding
16.4V, 160A @ 30% 18V, 200A @ 25%
Duty Cycle (%) 25% @ 125A 20% @ 200A
Welder Type Inverter Power Source
Output Terminal Type Heavy Duty Dinse TM 50
Classification
Protection Class IP23S
Standards EN 60974-1 EN50199
Cooling Method Fan Cooled
Dimensions and Weight
Welding Power Source Mass 10 kg (22 lb.)
Welding Power Source Dimensions (Height x
Width x Depth)
H230mm x W135mm x D450mm
( H 9.0” x W 5.3” x D 17.7”)
∆ The recommended time delay fuse or circuit breaker size is 32 amp for 110V and 32 amp for 230V.
