PARTS LISTS 6-4 Manual 0-2817
6.04 Replacement Machine Torch Parts
Item # Qty Description Catalog #
1 1 Shield Cup Assembly (includes item #2), 40A 9-8400
2 1 Spring, Canted Coil 9-7501
3 1 Tip, Cutting, (Refer to Appendix Page for the proper application)
1 Tip, Gouging, (Refer to Appendix Page for the proper application)
4 1 Distributor (Refer to Appendix Page for the proper application)
5 1 Electrode (Refer to Appendix Page for the proper application)
6 1 Assembly, Torch Head, PCM-62 (includes items #7 - 9) 9-8408
7 1 O - Ring (pkg of 5) 8-0532
8 1 #6-32 x 3/16 Phillips Pan Head Screw See Note
9 1 #6 Internal Star Washer See Note
10 1 Unshielded Lead Assembly, Cable Complete
25 ft (7.6 m) Length 4-0832
50 ft (15.2 m) Length 4-0833
11 1 Positioning Tube with Rack, Fiberglass 9-7835
12 2 Body, Mounting, Pinch Block Phenolic (Plastic) 9-4513
13 1 Pin, Mounting, Pinch Block 9-4521
14 1 Torch Holder Sleeve 7-2896
15 3 #10-32 x 5/8" Phillips Pan Head Screw See Note
16 2 #10-32 x 32 x 1 1/4 Lg Phillips Pan Head Screw See Note
17 2 #10-32 Regular Nylon Lock Nut See Note
18 1 Through - hole Protector, Notched (Supplied with Nut) 9-7016
19 3 Pin Housing (used with item #20) 9-5577
20 3 Pin 9-5763
21 3 Socket Housing (used with item #22) 9-5764
22 3 Socket 9-5578
23 1 Adapter, Machine Torch Control Cable 7-3448
24 1 Pinch Block Mounting Kit (includes items 12 - 17) 7-3252
Note: Item can be purchased locally.
