PARTS LISTS 46 Manual 0-2731
6.03 Complete System Replacements
Includes the following components: Power Supply with shielded input power cable, work cable and clamp, torch
and leads (as ordered), coolant, torch spare parts kit, CNC interface cable and operating manual.
Qty Description Catalog #
1 Merlin 1000 with 180° torch with 25 ft (7.6 m) Leads 1-9020
1 Merlin 1000 with 180° torch with 50 ft (15.2 m) Leads 1-9021
6.04 Power Supply Replacement Only
Includes: Power Supply with shielded input power cable, work cable and clamp
Qty Description Catalog #
1 Merlin 1000 Power Supply 3-9020
6.05 Basic Replacement Parts
Qty Description Catalog #
1 In-Line Filter 8-3460
1 Coolant Filter 8-4276
1 gal Torch Coolant
Standard 25/75 Mix for Ambient Temperatures to +10°F (-12°C) 7-2850
Super 50/50 Mix for Ambient Temperatures to -34°F (-36°C) 7-2959
1 Deionizer Bag 8-3312
1 Shielded Input Power Cable 9-7890
6.06 Options and Accessories
Qty Description Catalog #
1 Two Stage Air Filter Kit 9-1020
Replacement Elements
1 First Stage 9-1021
1 Second Stage 9-1022
1 Remote Pendant Control 7-3114
1 Remote Arc Starter Kit 3-6825
Includes internal Power Supply conversion and Remote Arc Starter assembly
1 Arc Starter Supply Leads (Used with Remote Arc Starter only)
Refer to Appendix V for parts list
