Table of Contents
Contents ........................................................................2
Additional Requirements .............................................2
Before you Start ............................................................2
483 Hardware ................................................................3
Status LED Indicators .................................................4
Testing the Control .....................................................4
Cleaning .....................................................................4
Apple Mac OSX Computer ...........................................5
Background ................................................................5
Installation of Computer .............................................5
Mac OS X Basics .......................................................5
Installation of Web Host Software ..............................5
Configuring Mac OS X ..................................................6
tekmarNet ® 4 Gateway Web Pages ..............................8
Networking Options ................................................... 13
Router Configuration for LAN ................................... 14
Router Configuration for Internet ............................. 16
Accessing the Gateway .............................................. 17
Updating the Web Host Software .............................. 19
Trademarks ................................................................. 19
Warranty ......................................................................20
tekmarNet ® 4 Gateway 483
Web Host Software USB - P9307
6 foot USB cable
Screwdriver
•
•
•
•
Wiring Brochure W483
Data Brochure D 483
Job Record J 483
User Brochure U 483
•
•
•
•
Contents
Additional Requirements
An Apple Mac computer with OS X version 10.5 Leopard,
10.6 Snow Leopard or 10.7 Lion is required. This computer
will be used as a web server to host the tekmarNet
®
Gateway web pages.
Web Browser
The tekmarNet ® 4 Gateway web pages can be viewed
from any computer that has one of the following web
browsers:
Internet Explorer version 6.0 or higher
Firefox version 2.0 or higher
Safari version 2.0 or higher
Compatible tekmarNet ® Products
The tekmarNet ® 4 Gateway 483 version J1193L is compatible
with the following products:
tekmarNet ® 4 Timer 033
Setpoint Control 161*, 162**
Boiler Control 274, 275
tekmarNet
® 2 Wiring Center 313, 314
tekmarNet ® 4 Wiring Center 315, 316
Zone Expansion Module 324, 325, 326
Zone Manager 334, 335, 336, 337
•
•
•
•
•
•
•
•
•
•
Power Manager 345, 346
tekmarNet
® 2 House Control 400, 401, 402, 403, 406
Boiler Reset Module 420
Mixing Reset Module 421
Universal Reset Module 422, 423
Mixing Expansion Module 440, 441, 444
tekmarNet
® 4 User Switch 479, 480, 481
tekmarNet ® 2 Thermostat 527, 528, 529, 530
tekmarNet ® 4 Thermostat 537, 538, 540, 541, 542,
543***, 544, 545, 546
tekmarNet
® Thermostat 552
* 161 versions J1141A and J1141B are not fully compatible
with the 483
** 162 versions J1142A and J1142B are not fully compatible
with the 483
*** 543 versions J1126A to J1126I are not fully compatible
with the 483
Please contact your tekmar sales representative for
assistance with affected 161, 162, and 543 products.
tekmarNet ® products not listed may not be compatible
with this version of the 483 software. Contact your tekmar
sales representative for information.
•
•
•
•
•
•
•
•
•
•
Before connecting the tekmarNet ® 4 Gateway 483 to a
tekmarNet ® system, it is recommended that the system
be fully completed, with no tekmarNet ® thermostats or
setpoint control’s being added or removed at a later date.
Also, each tekmarNet
® thermostat and setpoint control
device is automatically assigned a tekmarNet ® address
when connected to the system. It is recommended that
each device be given a manual address. This address
should be written down together with the room location
for future reference.
The gateway records the address of each tekmarNet ®
thermostat and setpoint control. For each address, the
installer can name the room location and building area for
each thermostat and setpoint control.
