CY7C1310AV18

CY7C1312AV18

CY7C1314AV18

PRELIMINARY

Document #: 38-05497 Rev. *A

Page 8 of 21

Write Cycle Descriptions

(CY7C1310AV18 and CY7C1312AV18)

[2, 8]

BWS

0

BWS

1

K

K

Comments

L

L

L-H

During the Data portion of a Write sequence

:

CY7C1310AV18

− both nibbles (D

[7:0]

) are written into the device,

CY7C1312AV18

− both bytes (D

[17:0]

) are written into the device.

L

L

L-H During the Data portion of a Write sequence

:

CY7C1310AV18

− both nibbles (D

[7:0]

) are written into the device,

CY7C1312AV18

− both bytes (D

[17:0]

) are written into the device.

L

H

L-H

During the Data portion of a Write sequence

:

CY7C1310AV18

− only the lower nibble (D

[3:0]

) is written into the device. D

[7:4]

will remain unaltered,

CY7C1312AV18

− only the lower byte (D

[8:0]

) is written into the device. D

[17:9]

will remain unaltered.

L

H

L-H During the Data portion of a Write sequence

:

CY7C1310AV18

− only the lower nibble (D

[3:0]

) is written into the device. D

[7:4]

will remain unaltered,

CY7C1312AV18

− only the lower byte (D

[8:0]

) is written into the device. D

[17:9]

will remain unaltered.

H

L

L-H

During the Data portion of a Write sequence

:

CY7C1310AV18

− only the upper nibble (D

[7:4]

) is written into the device. D

[3:0]

will remain unaltered,

CY7C1312AV18

− only the upper byte (D

[17:9]

) is written into the device. D

[8:0]

will remain unaltered.

H

L

L-H During the Data portion of a Write sequence

:

CY7C1310AV18

− only the upper nibble (D

[7:4]

) is written into the device. D

[3:0]

will remain unaltered,

CY7C1312AV18

− only the upper byte (D

[17:9]

) is written into the device. D

[8:0]

will remain unaltered.

H

H

L-H

No data is written into the devices during this portion of a write operation.

H

H

L-H No data is written into the devices during this portion of a write operation.

Write Cycle Descriptions

(CY7C1314AV18)

[2, 8]

BWS

0

BWS

1

BWS

2

BWS

3

K

K

Comments

L

L

L

L

L-H

-

During the Data portion of a Write sequence, all four bytes (D

[35:0]

) are written into

the device.

L

L

L

L

-

L-H During the Data portion of a Write sequence, all four bytes (D

[35:0]

) are written into

the device.

L

H

H

H

L-H

-

During the Data portion of a Write sequence, only the lower byte (D

[8:0]

) is written

into the device. D

[35:9]

will remain unaltered.

L

H

H

H

-

L-H During the Data portion of a Write sequence, only the lower byte (D

[8:0]

) is written

into the device. D

[35:9]

will remain unaltered.

H

L

H

H

L-H

-

During the Data portion of a Write sequence, only the byte (D

[17:9]

) is written into

the device. D

[8:0]

and D

[35:18]

will remain unaltered.

H

L

H

H

-

L-H During the Data portion of a Write sequence, only the byte (D

[17:9]

) is written into

the device. D

[8:0]

and D

[35:18]

will remain unaltered.

H

H

L

H

L-H

-

During the Data portion of a Write sequence, only the byte (D

[26:18]

) is written into

the device. D

[17:0]

and D

[35:27]

will remain unaltered.

H

H

L

H

-

L-H During the Data portion of a Write sequence, only the byte (D

[26:18]

) is written into

the device. D

[17:0]

and D

[35:27]

will remain unaltered.

H

H

H

L

L-H

During the Data portion of a Write sequence, only the byte (D

[35:27]

) is written into

the device. D

[26:0]

will remain unaltered.

H

H

H

L

-

L-H During the Data portion of a Write sequence, only the byte (D

[35:27]

) is written into

the device. D

[26:0]

will remain unaltered.

H

H

H

H

L-H

-

No data is written into the device during this portion of a write operation.

H

H

H

H

-

L-H No data is written into the device during this portion of a write operation.
