Photoflex, Warranty – Photoflex FV-SODXS222KT OctoDome nxt: Extra Small Kit User Manual
Page 3

Visit photoflex
lightingschool
.com® for the best free learning resource!
For detailed specifications,
product tutorial videos
and more, please visit
www.photoflex
®
.com
Figure 18.
Figure 19.
Attach Inner Baffle & Front face to the Softbox
19. With both the front face and inner baffle attached, the light
will be softest. For a little more contrast, try using just the
baffle. The baffle installs to the Velcro
®
tabs (Figs. 20-21)
20. The front face diffuser is rimmed with Velcro
®
that attaches
to its counterpart lining at the front of the OctoDome.
Starting at any corner, press the face diffuser in place
working your way around the circumference (Figs. 22-23)
21. The front face is usually best when attached halfway into
the Velcro
®
section. When using the optional grid, it may
be preferred to leave more Velcro
®
showing for the grid.
Using Optional Accessories (Not Included)
22. For added control of your light, softbox grids can be used.
The grid will attach using Velcro
®
in front of your diffusion
face (Fig. 24).
Figure 21.
Figure 20.
Figure 22.
Figure 24.
Figure 23.
PHOTOFLEX
®
WARRANTY
• Warranties only cover manufacturer’s defects and workmanship
• OctoDome has a 6 year warranty. All other kit items have a 5 year
warranty
• We reserve the right to inspect all merchandise returned (end users
and dealers) for warranty fulfillment.
• For returns contact Photoflex first to obtain a return authorization
number and instructions for return.
• Freight must be paid by the customer or dealer.
• Warranties are valid only from date of Original Purchase.
Customer Support (800) 486-2674
email: [email protected]
Corporate Office (831) 786-1370 • FAX (831) 786-1372
97 Hangar Way, Watsonville, CA 95076
