5 YEAR PHOTOFLEX

®

WARRANTY

• LitePanel

®

Hardware has a Five Year Warranty

• Warranties only cover manufacturer’s defects and workmanship
• We reserve the right to inspect all merchandise returned (end users

and dealers) for warranty fulfillment.
• All returns must be accompanied by a receipt showing date of

purchase.
• Freight must be paid by the customer or dealer.
• Warranties are valid only from date of Original Purchase.

Figure 9.

Figure 10. 39” x 39” LitePanel/
LiteReach Kit

Figure 7.

Figure 8.

Alternatively, the hardware can be attached so that the track plate
is facing out from the edge of the frame. In this configuration, a
second fabric can be attached on the opposite side for a quick
change of reflector surfaces or for double diffusion.

Figure 7

Step 5 With either one or two upper and lower components
attached to the frame. Slide the swivel stand mount onto the
swivel track on the lower plate and tighten the set screw knob.
Figures 8-9
Tip: When using the LitePanels extended like a boom as
shown in figure 10, put the swivel handle on your left side
when attaching it to the mounting track. In this way, gravity
works with you allowing the weight of the LitePanel to further
tighten the swivel rather than loosen it.
With the Hardware securely attached, it is now ready to be
placed on a Photoflex LiteStand or the LiteReach Plus hand held
extension.

Figures 10-12
