photoflex lightingschool .com®
For warranty registration and information, please visit www.photoflex.com®
Customer Support (800) 486-2674
email: [email protected] ®
Corporate Office (831) 786-1370 • FAX (831) 786-1371
97 Hangar Way, Watsonville, CA 95076
PHOTOFLEX ® WARRANTY
• Warranties only cover manufacturer’s defects and workmanship.
• We reserve the right to inspect all merchandise returned (end users
and dealers) for warranty fulfillment.
• All returns must be accompanied by a receipt showing date of
purchase.
• Freight must be paid both ways by the customer or dealer.
• Warranties are valid only from date of Original Purchase.
Start by lining up the long edge
of the Grid to the long edge of
the SoftBox.
Move to adjacent corner and
press in place.
Press one corner on the Grid to
a corner of the SoftBox.
Begin working your way along
each edge to secure.
Continue around the perimeter
of the SoftBox until the Grid is
completely secured.
Press your Grid in place at one
corner of the SoftBox using the
Velcro ® edges.
The Grid of the OctoDome ® is
installed by attaching the Velcro ®
lining on the perimeter of the Grid
to the 3 inch Velcro ® counterpart
sewn on the 8 sides of the rim of the
OctoDome ®
Stretch the Grid and press the
last two corners in place.
Press the Grid in place along
one side of the SoftBox.
Secure the last edge to the Soft
Box and you're ready to shoot.
The OctoDome ® Grid will restrict
light output to fall only in front of
the SoftBox.
LiteDome ® /HalfDome ® Grid Instructions OctoDome ® Grid Instructions
