10. Once your start point has been set, press the the MIDDLE
JOYSTICK BUTTON or ENTER to begin the calibration
11. The screen will display Slider On with a countdown.
12. Let the calibration complete. If you need to cut the calibration
short you can hit the MENU Button at any time.
NOTE:
The shorter the calibration time, the less accurate the calibration.
13. To complete the calibration, measure the distance between
your start point (A) and ending point (B).
14 Move the joystick LEFT/RIGHT to adjust the values in the
ORACLE to match the distance in inches or centimeters that
the carriage moved during the calibration.
This number will vary in distance depending on your specific
setup / motor selection.
Press ENTER or the MIDDLE JOYSTICK BUTTON to confirm
15. Press ENTER or the MIDDLE JOYSTICK BUTTON again to save
calibration data, or MENU to cancel calibration data.
Set Start Point
ENTER: Begin
Slider 6M 30S
Calibration
SLIDER/DOLLY TIME LAPSE CALIBRATION
MOTION CONTROL - SIMPLE
CONTINUED
16. Your system is now calibrated for accurate moves as the
ORACLE now knows how far over time the carriage will move
with setup used in calibration.
Quick Tip:
If moving between extreme environmental conditions, major camera
weight changes, or different incline angles, we recommend running the
calibration again to insure accuracy.
Adj Dist Moved
2.75IN 6.98CM
