E-flite Taylorcraft 450 ARF - Manual (Page 3)

3 E-flite Taylorcraft ARF Assembly Manual
Using the Manual
This manual is divided into sections to help make assembly
easier to understand, and to provide breaks between each
major section. In addition, check boxes have been placed next
to each step to keep track of each step completed. Steps with
a single circle () are performed once, while steps with two
circles ( ) indicate that the step will require repeating, such
as for a right or left wing panel, two servos, etc.
Remember to take your time and follow the directions.
Contents of Kit/Parts Layout
Replacement Parts
EFL2626 Wing Set w/Ailerons
EFL2627 Fuselage
EFL2628 Tail Set
EFL2629 Cowling
EFL2630 Landing Gear & Covers
EFL2631 Wheel Pants
EFL2632 Pushrod Set
EFL2633 Fuselage Hatch
EFL2634 Window Set
EFL2635 Wing Strut Set
Required Radio Equipment
You will need a minimum 4-channel transmitter, crystals (for
72MHz), micro receiver, and four sub-micro servos. You can
choose to purchase a complete radio system that includes
all of these items or, if you are using an existing transmitter,
just purchase the other required equipment separately. We
recommend the crystal-free, interference-free Spektrum ™
DX6i 2.4GHz DSM 6 channel system, which includes a micro
receiver. You will need to purchase 4 sub-micro 7.5 gram
servos. If using your own transmitter, we recommend the use of
a JR SPORT ™ 6-channel UltraLite receiver and E-flite ® S75 Super
Sub-Micro servos.
Complete Radio System
SPM6600 DX6i DSM 6CH Radio System
Or Purchase Separately
JSP30610 6-Channel UltraLite Rx w/o Crystal, Positive Shift JR/
AIR (72MHz)
JSP30615 6-Channel UltraLite Rx w/o Crystal, Negative Shift
Fut/HRC (72MHz)
JRPXFR** FM Receiver Crystal (JR only,
not AR6000)
Or
SPM6000 AR6000 DSM 6-Channel Park Flyer Receiver
(DX6 users only)
Or
SPM6100 AR6100 DSM3 Micro Lite 6-Channel Receiver, Air
(DX7 users only)
And
EFLRS75 7.5-gram Sub-Micro Servo (4)
EFLREX6L 6-inch Extension Lead (2)
JSP98020 Y-harness
