25 E-flite Taylorcraft ARF Assembly Manual
 7. Repeat Steps 1 through 6 to install the elevator
pushrod and servo.
Landing Gear Installation
Required Parts
Landing gear Landing gear cover (2)
#4 washer (4) 4-40 locknut (4)
4-40 nut (2) 1 3 / 4
-inch (44mm) foam wheel (2)
Wheel pant (R&L) 2mmx 8mm sheet metal screw (2)
4-40 x 1 1 / 4
-inch socket head screw (2)
4-40 x 3/8-inch socket head screw (2)
2mm x 6mm machine screw (4)
Required Tools and Adhesives
Pin drill Drill bit: 1/16-inch (1.5mm)
Hex wrench: 3/32-inch #1 Phillips screwdriver
Felt-tipped pen Pliers
Threadlock
 1. Attach the landing gear covers to the landing gear
using four 2mm x 6mm machine screws. The front edge
of the covers will line up with the front edge of the
landing gear when installed correctly.
