14 E-flite Taylorcraft ARF Assembly Manual
Joining the Wing Panels
Required Parts
Wing (R&L) Wing joiner
Wing dowel (2) Skylight window
Wing bolt brace
2mm x 6mm sheet metal screw (8)
Required Tools and Adhesives
Pencil 30-minute epoxy
Mixing stick Epoxy brush
Hobby knife w#11 blade Felt-tipped pen
Medium CA Low-tack masking tape
Medium grit sandpaper Paper towels
Rubbing alcohol #1 Phillips screwdriver
 1. Use a pencil to mark the wing panel and joiner so you
can return the joiner into the orientation in which it was
fit into the wing panels.
 2. Slide the wing joiner into the wing panel. It may be
necessary to sand it lightly for the best fit.
 3. Use a pencil to draw a line on the joiner against
the wing.
