23 E-flite Taylorcraft ARF Assembly Manual
Servo Installation
Required Parts
Control horn (2) Control horn backplate (2)
Micro pushrod connector (2) Connector backplate (2)
2mm x 4mm machine screw (2)
Pushrod wire, 24-inch (610mm) (2)
Required Tools and Adhesives
Medium CA Low-tack masking tape
#1 Phillips screwdriver Side cutters
  1. Pass the bend in the 24-inch (610mm) pushrod wire
through the center hole of the control horn.
  2. Slide the pushrod wire into the pre-installed pushrod
tube in the fuselage.
  3. Insert the control horn into the slot in the rudder.
Hint: Use low-tack masking tape to hold the rudder and
elevator centered while installing the servos.
