Wing installation – E-flite Brio 10 ARF User Manual
Page 21
Wing Installation
Required Parts
• Fuselage
• Wing (right and left)
• Wing tube
• #4 washer (2)
• 4-40 x 1/2" socket head screw (2)
Required Tools and Adhesives
• Hex wrench: 3/32"
1. Slide the wing tube into a wing panel.
2. Remove the hatch from the fuselage. Slide
the wing panel with tube into position on
the fuselage.
21
