Landing Gear Installation
Required Parts
• Fuselage • Main landing gear (L&R)
• Tail skid • Wheel pant (L&R)
• 2mm nut (6) • #4 washer (4)
• 1 3
/
8
" (35mm) wheel (2)
• 2mm x 25mm screw (2)
• 4-40 x 1/2" socket screw (4)
• 2mm x 8mm wood screw (2)
Required Tools and Adhesives
• Threadlock • Drill bit: 1/8" (3mm)
• Drill • Medium CA
• Hobby knife • Hex wrench: 3/32"
• Thin CA
• Phillips screwdriver (small)
Note: You may consider using a larger
diameter wheel, such as 2
1
/
4
" (58mm), if your
flying site has rough terrain. By using a larger
wheel, you will not be able to use the included
wheel pants.
 1. Use a hobby knife with a new blade to remove
the covering from the fuselage where the landing
gear will be inserted.
