Rating for DX85 models:IEC IP67; NEMA 6; (See UL
section below for any applicable UL specifications)
Rating for DX85...C models: IEC IP20; NEMA 1 (In a
suitable enclosure: Class I, Division 2, Group A, B, C,
D; T4 −40 to 80° C)
Operating Temperature: −40 to +85° C (Electronics);
−20 to +80° C (LCD)
Operating Humidity: 95% max. relative (non-condens-
ing)
Radiated Immunity: 10 V/m, 80-2700 MHz
(EN61000-6-2)
Shock: 30g, 11 millisecond half sine wave, 18 shocks
Vibration: 0.5 mm p-p, 10 to 60 Hz
Refer to the SureCross™ DX80 Wireless I/O Network product manual, Banner p/n 132607, for installation and waterproofing instructions.
Operating the devices at the maximum operating conditions for extended periods can shorten the life of the device.
Certifications
DX8x...C (External Wiring Terminal Models)
CSA: Class I, Division 2, Groups A, B, C, D (Ex/A Ex nA II T4); Certificate: 1921239
LCIE/ATEX: Zone 2 (II 3G / Ex nA IIC); Certificate: LCIE 10 ATEX 1012 X
UL Listing
Maximum ambient temperature: 70°C
Mounting instructions: See document 132607
Power rating: 10 to 30V dc, UL Class 2
Enclosure environmental rating: UL Type 1
Included with Device (DX85 and DX85...C Models)
The following items ship with the DX85 models.
Included with Device
Model
Qty
Item
DX80 Access Hardware Kit *
BWA-HW-002
4
Plastic threaded plugs, PG-7
4
Nylon gland fittings, PG-7
4
Hex nuts, PG-7
1
Plug, 1/2" NPT
1
Nylon gland fitting, 1/2" NPT
Mounting Hardware Kit
BWA-HW-001
4
Screw, M5-0.8 x 25mm, SS
4
Screw, M5-0.8 x 16mm, SS
4
Hex nut, M5-0.8mm, SS
4
Bolt, #8-32 x 3/4", SS
PTFE Tape *
BWA-HW-003
1
PTFE Tape
SureCross Literature CD
79685
1
SureCross Literature CD
Cable
MQDC1-506
1
Cable, 5-pin Euro (single ended), Straight, 2m
BWA-HW-011
1
IP20 Screw Terminal Headers (2 pack) (ships with DX85...C
models only)
* Not included with DX85...C models.
