Banner SureCross DX85 Modbus RTU Remote I/O Device - Manual

Configurable Modbus slave remote I/O device with eight sourcing discrete inputs and four sourcing discrete outputs
Features
IP67 Base
IP20 Base
The SureCross™ wireless system is a radio frequency network with integrated I/O that
can operate in most environments while eliminating the need for wiring runs. Systems are
built around a Gateway, which acts as the wireless network master device, and one or
more Nodes. A remote I/O device with a Modbus interface is used to expand the I/O of the
Gateway device or the Modbus host.
• Wireless industrial I/O device with eight sourcing discrete inputs and four sourcing dis-
crete outputs
• 10 to 30V dc power input
• Selectable Modbus slave address
• Modbus RTU protocol using RS-485
• The DX85...C models are certified for use in Class I, Division 2, Group A, B, C, D; and
Zone 2 (Group IIC) Hazardous Locations when properly installed in accordance with
the National Electrical Code, the Canadian Electrical Code, LCIE/ATEX, or applicable
local codes/regulations (see Specifications)
For additional information, the most recent version of all documentation, and a complete list of accessories, refer to Banner Engineering's
website,
www.bannerengineering.com/surecross .
Models
Model Environmental Rating I/O
DX85M8P4 IP67, NEMA 6
Inputs: Eight sourcing discrete
Outputs: Four sourcing discrete
DX85M8P4C
IP20, NEMA 1
Class I, Division 2, Group A, B, C, D Hazardous Lo-
cations (see Specifications)
WARNING: Not To Be Used for Personnel Protection
Never use this product as a sensing device for personnel protection. Doing so could lead to seri-
ous injury or death. This product does NOT include the self-checking redundant circuitry necessary to
allow its use in personnel safety applications. A sensor failure or malfunction can cause either an ener-
gized or de-energized sensor output condition.
SureCross DX85 Modbus RTU Remote I/O Device
P/N 134324 rev. F 1/11/2012
