U-GAGE ™ T30 Series with Analog and Discrete Outputs
P/N 57438 Rev. C 9
Banner Engineering Corp. • Minneapolis, MN U.S.A.
www.bannerengineering.com • Tel: 763.544.3164
Quick-Disconnect (QD) Cables
Accessories
5-Pin
Euro-style
Right-angle
with shield
5-Pin
Euro-style
Straight
with shield
MQDEC2-506
MQDEC2-515
MQDEC2-530 2 m (6.5')
5 m (15')
9 m (30')
Style Model Length Connector
MQDEC2-506RA
MQDEC2-515RA
MQDEC2-530RA 2 m (6.5')
5 m (15')
9 m (30')
Style Model
M12 x 1
ø 15 mm
(0.6")
44 mm max.
(1.7")
Length Connector
38 mm max.
(1.5")
M12 x 1
ø 15 mm
(0.6")
38 mm max.
(1.5")
Mounting Brackets
SMB30A
• Angled-mount bracket
• Stainless steel
SMB1815SF
• Compact 30 mm split clamp with swivel, black
reinforced thermoplastic polyester
• Stainless steel hardware included
ø 30.5 mm
(1.20") 38.5 mm
(1.52")
61 mm
(2.40")
69 mm
(2.70")
30 °
45 mm
(1.8")
R 40 mm
(1.58")
ø 6.3 mm
(0.25")*
6.3 mm
(0.25")*
* Use 5 mm (#10) screws to mount bracket.
Drill screw holes 40.0 mm (1.58") apart.
7.6 mm
(0.30")
36.0 mm
(1.42")
50.8 mm
(2.00")
42.0 mm
(1.65")
22.9 mm
(0.9")
25.4 mm
(1.00")
10.6 mm
(0.42")
ø15.0 mm
(0.59")
