U-GAGE
™
T30 Series with Analog and Discrete Outputs
P/N 57438 Rev. C
7
Banner Engineering Corp.
•
Minneapolis, MN U.S.A.
www.bannerengineering.com • Tel: 763.544.3164
U-GAGE T30 Series Specifications (continued)
Construction
Environmental Rating
Leakproof design is rated IEC IP67; NEMA 6P
Molded reinforced thermoplastic polyester housing
Vibration and
Mechanical Shock
All models meet Mil. Std. 202F requirements. Method 201A (Vibration: 10 to 60Hz max., double amplitude
0.06", maximum acceleration 10G). Also meets IEC 947-5-2 requirements: 30G, 11 ms duration, half sine wave.
Operating Conditions
Temperature: -20° to +70° C (-4° to 158° F)
Maximum relative humidity: 100%
Application Notes
Objects passing inside the specified near limit will produce a false response.
NOTE: For more information about out-of-range and signal loss response of the analog output, see page 5.
Connections
2 m (6.5') or 9 m (30') 5-conductor PVC-covered attached cable, or 5-pin Euro-style quick-disconnect
fitting (see page 9 for optional quick-disconnect cables)
U-GAGE T30 Series Performance Curves
U-GAGE T30 Effective Beam with Plate Target (Typical)
1-Meter Models
2-Meter Models
U-GAGE T30 Effective Beam with Rod Target (Typical)
1-Meter Models
2-Meter Models
0
0
200 mm
(8.0 in)
400 mm
(16.0 in)
600 mm
(24.0 in)
800 mm
(32.0 in)
1000 mm
(40.0 in)
50 mm
50 mm
100 mm
100 mm
150 mm
150 mm
200 mm
200 mm
0
2.0 in
2.0 in
4.0 in
4.0 in
6.0 in
6.0 in
8.0 in
8.0 in
100 x 100 mm
10 x 10 mm
Width
Distance
0
0
400 mm
(16.0 in)
800 mm
(32.0 in)
1200 mm
(48.0 in)
1600 mm
(64.0 in)
2000 mm
(80.0 in)
100 mm
100 mm
200 mm
200 mm
300 mm
300 mm
400 mm
400 mm
0
4.0 in
4.0 in
8.0 in
8.0 in
12.0 in
12.0 in
16.0 in
16.0 in
100 x 100 mm
Width
Distance
0
0
200 mm
(8.0 in)
400 mm
(16.0 in)
600 mm
(24.0 in)
800 mm
(32.0 in)
1000 mm
(40.0 in)
50 mm
50 mm
100 mm
100 mm
150 mm
150 mm
200 mm
200 mm
0
2.0 in
2.0 in
4.0 in
4.0 in
6.0 in
6.0 in
8.0 in
8.0 in
25 mm Rod
10 mm Rod
Width
Distance
0
0
400 mm
(16.0 in)
800 mm
(32.0 in)
1200 mm
(48.0 in)
1600 mm
(64.0 in)
2000 mm
(80.0 in)
100 mm
100 mm
200 mm
200 mm
300 mm
300 mm
400 mm
400 mm
0
4.0 in
4.0 in
8.0 in
8.0 in
12.0 in
12.0 in
16.0 in
16.0 in
25 mm Rod
Width
Distance
Certifications
