Specifications
9
Banner Engineering Corp. • Minneapolis, U.S.A.
Website: http://www.baneng.com • Tel: 888.373.6767
10.2 mm
(0.40")
L3
38.1 mm
Square
(1.50")
53.8 mm
(2.12")
2.5 mm
(0.10")
18.3 mm
(0.72")
*Distance X to
First Beam
L1
71 mm
(2.8")
R13 mm (0.5")
Minimum Bend
L2
Figure 2-1. Emitter and receiver dimensions
With mounting bracket flanges “in”
With mounting bracket flanges “out”
*Dis tance X to First Beam
3/4" Beam Spacing: 42.9 mm (1.69")
3/8" Beam Spacing: 38.1 mm (1.50")
3/4" Beam Spacing (16 Beams/Foot)
Distance X: 42.9 mm (1.69")
3/8" Beam Spacing (32 Beams/Foot)
Distance X: 38.1 mm (1.50")
Housing Length
Distance Between Bracket Holes
Models
Beams
Models
Beams
L1
L2
L3
BMEL616A Emitter
BMRL616A Receiver
8
8
BMEL632A Emitter
BMRL632A Receiver
16
16
201 mm
(7.9")
234 mm
(9.2")
177 mm
(7.0")
BMEL1216A Emitter
BMRL1216A Receiver
16
16
BMEL1232A Emitter
BMRL1232A Receiver
32
32
356 mm
(14.0")
390 mm
(15.4")
333 mm
(13.1")
BMEL1816A Emitter
BMRL1816A Receiver
24
24
BMEL1832A Emitter
BMRL1832A Receiver
48
48
505 mm
(19.9")
539 mm
(21.2")
482 mm
(19.0")
BMEL2416A Emitter
BMRL2416A Receiver
32
32
BMEL2432A Emitter
BMRL2432A Receiver
64
64
659 mm
(26.0")
693 mm
(27.3")
636 mm
(25.1")
BMEL3016A Emitter
BMRL3016A Receiver
40
40
BMEL3032A Emitter
BMRL3032A Receiver
80
80
810 mm
(31.9")
844 mm
(33.2")
787 mm
(31.0")
BMEL3616A Emitter
BMRL3616A Receiver
48
48
BMEL3632A Emitter
BMRL3632A Receiver
96
96
963 mm
(37.9")
997 mm
(39.3")
941 mm
(37.0")
BMEL4216A Emitter
BMRL4216A Receiver
56
56
BMEL4232A Emitter
BMRL4232A Receiver
112
112
1115 mm
(43.9")
1148 mm
(45.2")
1091 mm
(43.0")
BMEL4816A Emitter
BMRL4816A Receiver
64
64
BMEL4832A Emitter
BMRL4832A Receiver
128
128
1267 mm
(49.9")
1301 mm
(51.2")
1244 mm
(49.0")
BMEL6016A Emitter
BMRL6016A Receiver
80
80
BMEL6032A Emitter
BMRL6032A Receiver
160
160
1572 mm
(61.9")
1606 mm
(63.2")
1549 mm
(61.0")
BMEL7216A Emitter
BMRL7216A Receiver
96
96
BMEL7232A Emitter
BMRL7232A Receiver
192
192
1877 mm
(73.9")
1910 mm
(75.2")
1853 mm
(73.0")
