Specifications
10
Banner Engineering Corp. • Minneapolis, U.S.A.
Website: http://www.baneng.com • Tel: 888.373.6767
2.2 Control Module with DeviceNet Specifications
DeviceNet Configurations Vendor code: 12 (Banner Corp.)
Device type: 110
Product code: 1 (MACNXDN-1)
2 (MACPXDN-1)
Connection types supported: Explicit Message, Poll, COS
Network address: 0-63 (network configured)
Baud rate supported: 125K, 250K, 500K (network configured)
Output Configurations MACNXDN-1: Two PNP discrete (switched)
MACPXDN-1: Two NPN discrete (switched)
Power Requirements* Controller, emitter and receiver: 16 to 30V dc @ 1.2 A max. (typical: 0.5 A @ 16V dc)
Inputs Sensor input: Emitter and receiver wire in parallel to five terminals.
Gate input: Optically isolated, requires 10 to 30V dc (7.5kΩ impedance) for gate signal
Discrete (Switched) Outputs NPN outputs: Open collector NPN transistor rated at 30V dc max., 150 mA max.
PNP outputs: Open collector PNP transistor rated at 30V dc max., 150 mA max.
All discrete outputs:
OFF-state leakage current: < 10 µA @ 30V dc
ON-state saturation voltage: < 1V @ 10 mA and < 1.5V @ 150 mA
System Programming Via DeviceNet interface and supplied EDS files.
System Status Indicators Output (steady red): Output #1 energized.
Alarm (flashing red): Output #2 energized.
Gate (steady red): Gate input status.
Alignment (steady green): Proper emitter/receiver alignment and a clear, unblocked light screen (ON when
green or green/yellow receiver LEDs are ON.
Diag 1 (green), Diag 2 (red), Diag 3 (red): Used in combination to display System status; see Chapter 5,
System Diagnostics for more information.
Network Status Indicator Bi-colored (red/green) LED visible on the control module front panel indicates network status:
Steady Green: On-line, connected to master
Flashing Green: On-line, address and baud rate OK
Steady Red: Critical network fault or duplicate node address detected
Flashing Red: Connection timeout
OFF: No network power or off-line
Construction Polycarbonate housing; mounts to flat surface or directly onto 35-mm DIN rail
Environmental Rating NEMA 1 (IP20)
Operating Conditions Temperature: -20° to +70°C (-4° to 158°F)
Maximum relative humidity: 95% @ 50°C (non-condensing)
DeviceNet Power* 11 to 25V dc - supplied by DeviceNet BUS Network
*Application Note The controller must be powered up before the DeviceNet connection in every power-up situation
for proper operation
