2.3 DeviceNet Attribute Information
I/O Data Attribute Format, Poll and COS
I/O Data Mapping
BYTE BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0
0 X
System Status
Bit 2
System Status
Bit 1
System Status
Bit 0
X X
Alignment
Blocked
Alignment
OK
1 LSB – Measurement Mode 1*
2 MSB – Measurement Mode 1*
3 LSB – Measurement Mode 2*
4 MSB – Measurement Mode 2*
5 Reserved (always 0)
I/O Message Types Polled COS
Produced Data Size 8 bytes 8 bytes
Consumed Data Size 0 bytes 0 bytes
SYSTEM STATUS: (BYTE 0, NIBBLE 2):
1 EEPROM error
2 Controller error
3 ROM error
4 Normal
5 Emitter error
6 Receiver error
7
Emitter/receiver
mismatch
