Specifications – Banner A-GAGE MINI-ARRAY Series User Manual
Page 11
Specifications
11
Banner Engineering Corp. • Minneapolis, U.S.A.
Website: http://www.baneng.com • Tel: 888.373.6767
81.0 mm
(3.19")
115.0 mm
(4.53")
106.0 mm
(4.17")
35.0 mm
(1.38")
DIN mounting slot
Slot for M3.5 screws (2)
5.5 mm
(0.22")
69.0 mm
(2.72 ")
5.0 mm
(0.20")
96.0 mm
(3.78")
Figure 2-2. Control module dimensions
