L-GAGE® LT7 Long-Range Time-of-Flight Sensor
Main
Menu Procedure
Example Displays Result
QuickSet
Press
ESC
or
ESC
to scroll
through Main menu options
QuickSet
TEACH IN
OFFSET
UNIT
SERIAL
RS422
PASSWORD
FACTORY
Sensor scrolls through Main menu options.
See following steps for procedures if other than QuickSet is
selected.
With QuickSet visible on the
display, press
ESC
QuickSet Sensor enters QuickSet program.
Press
ESC
to teach current
condition to Output 1.
Press
ESC
to teach current
condition Output 2.
Q1 Q2
q1 Q2
196
196 mm to target
Output 1 OFF
Output 2 ON
Bars indicate a strong signal
Current measured value is displayed on top line; received energy
value is indicated by bar graph (the more bars, the stronger the
received signal). Outputs Q1 and Q2 are indicated as ON or OFF by
the LED status indicators and by whether the “Q” is capitalized on
the display (Q1 = Output 1 ON; q1 = Output 1 OFF).
Press
ESC
– or –
Use Escape function*
Sensor saves settings and returns to Main menu.
* Escape function available throughout Programming mode; returns sensor one step higher in menu.
