6
P/N 120244 Rev. B
Procedure Example Displays Result
Programming Mode
No P
assword
From Run mode, press
ESC
QuickSet If password is not required (factory preset condition), sensor proceeds
to QuickSet on the Main menu (Figure 7).
Password R
equired
From Run mode, press
ESC
PASSWORD
_ _ _ _
Blinking
Cursor
Sensor waits for valid password (1234); cursor blinks on right-hand
digit. If no password is begun within 10 seconds, sensor returns
automatically to Run mode.
Press
ESC
button 4 times,* then
press
ESC
PASSWORD
_ _ _ 4
Sensor inserts a 4 in the right-hand digit, then moves blinking cursor to
third position.
Press
ESC
button 3 times, then
press
ESC
PASSWORD
_ _ 3 4
Sensor inserts a 3 in the third digit, then moves blinking cursor to
second position.
Press
ESC
button twice, then
press
ESC
PASSWORD
_ 2 3 4
Sensor inserts a 2 in the second digit, then moves blinking cursor to
first position.
Press
ESC
button once, then press
ESC
PASSWORD
1 2 3 4
Sensor displays completed password and OK message, then proceeds
to QuickSet on the Main menu.
PASSWORD
OK!
QuickSet
ENTER
* Either arrow button may be pressed;
ESC
button will decrease number by one each time.
