Radio and General
Range
900 MHz: Up to 4.8 kilometers (3 miles)
2.4 GHz: Up to 3.2 kilometers (2 miles)
Transmit Power
900 MHz: 21 dBm conducted
2.4 GHz: 18 dBm conducted, less than or equal to 20
dBm EIRP
900 MHz Compliance (150 mW Radios)
FCC ID TGUDX80 - This device complies with FCC
Part 15, Subpart C, 15.247
IC: 7044A-DX8009
2.4 GHz Compliance
FCC ID UE300DX80-2400 - This device complies with
FCC Part 15, Subpart C, 15.247
ETSI/EN: In accordance with EN 300 328: V1.7.1
(2006-05)
IC: 7044A-DX8024
Spread Spectrum Technology
FHSS (Frequency Hopping Spread Spectrum)
Link Timeout
Gateway: Configurable
Node: Defined by Gateway
Radio range is with the 2 dB antenna that ships with the product.
High-gain antennas are available, but the range depends on the
environment and line of sight. To determine the range of your wire-
less network, perform a Site Survey.
Power
Requirements: +10 to 30V dc or +3.6 to 5.5V dc low
power option (Outside the USA: +12 to 24V dc, ±10%
or +3.6 to 5.5V dc low power option)
Consumption: Less than 1.4 W (60 mA) at 24V dc
Housing
Polycarbonate housing and rotary dial cover; polyester
labels; EDPM rubber cover gasket; nitrile rubber, non-
sulphur cured button covers
Weight: 0.26 kg (0.57 lbs)
Mounting: #10 or M5 (SS M5 hardware included)
Max. Tightening Torque: 0.56 N·m (5 lbf·in)
Antenna Connection
Ext. Reverse Polarity SMA, 50 Ohms
Max Tightening Torque: 0.45 N·m (4 lbf·in)
Interface
Indicators: Two bi-color LEDs
Buttons: Two
Display: Six character LCD
Wiring Access
Four PG-7, One 1/2-inch NPT, One 5-pin Euro-style
male connector
For European applications, power the DX80 from a Limited Power
Source as defined in EN 60950-1.
Inputs and Outputs
Discrete Input Rating
3 mA max current at 30V dc
Discrete Input Sample/Report Rates
125 milliseconds
Discrete Input ON Condition
PNP: Greater than 8V
NPN: Less than 0.7V
Discrete Input OFF Condition
PNP: Less than 5V
NPN: Greater than 2V or open
Counter Inputs
Threshold: 1.5V or 0.25V (Sinking or sourcing selected
inputs require the 1.5V threshold setting)
Debouce: DIP Switch Selectable. Enable debounce to
filter a noisy input signal that may lead to false triggers.
Event Counter: Input rating 1 Hz to 10 kHz (For battery
powered devices, the recommended input rating is less
than 1 kHz)
Rate (Frequency) Counter: 1 Hz to 25 kHz
Threshold (sinking counter on Performance and Multi-
Hop models) : 1.7V
Discrete Output Rating (NMOS)
Less than 10 mA max current at 30V dc
ON-State Saturation: Less than 0.7V at 20 mA
Discrete Output Update Rate
1 second
Discrete Output ON Condition
Less than 0.7V
Discrete Output OFF Condition
Open
Output State Following Timeout
De-energized (OFF)
