6 Devices
IC Net 2.1 84
Enabled Enable time program start (a disabled pro-
gram is not started).
Show flow column Show Flow column in the program table.
Add a new line to the time program.
Delete the selected line from the time pro-
gram.
Start all pump drives.
Interfaces
The Interfaces tab of the SDU window is only available for a con-
nected system.
Number of eluents Number of eluents used for gradient mixing.
Pumps List of used pumps for gradient mixing.
Clicking on
, , , or opens the
709 IC Pump window for parameter settings
and manual control of the selected pump.
Pressure checking Selection of the pump whose pressure is
checked using the
Min/Max pressure limits.
Time reaction for press. min/max overflow
Time delay for pump stopping at Min/Max
pressure limits.
Links
The Links tab of the Metrohm SDU is used for COM port selection
and settings (details see section 5.2.4).
