8 Chromatograms
IC Net 2.1 176
During active data acquisition the elapsed time, the duration of
the chromatogram or program and the current X and Y values are
shown in the second field of the status bar. If the peak editor is
switched on then the position of the cursor will be shown.
A chromatogram can be scaled with the help of keyboard or
mouse functions or through the
Chromatogram axes
window
opened with IC NET / View / Appearance / Chromatogram axes . Some
of the window control functions are collected in the Window menu.
8.2 Chromatogram file handling
8.2.1 Open chromatogram
IC NET / File / Open / Chromatogram
Load an existing chromatogram file (
*.chw
) from the
Data
directory
and open the chromatogram window. The following window ap-
pears:
