5.7 Lift position for the washing station ￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
52 ￭￭￭￭￭￭￭￭ 815 Robotic Soliprep for LC
6 Click on the associated [Assign] button.
7 Click on [Close].
5.7 Lift position for the washing station
External position 1
These settings apply to tower 2.
1 Move the lift upward until the Polytron is at a suitable height for swing-
ing to the washing station. Click on the arrow button [Arrow
down] and also (if required) [Arrow up] under lift position in order to
set a suitable position.
2 Under Robotic arm position click on the button [Arrow left] until
the robotic arm stops.
3 Click on [Configure rack].
4 Under Robotic arm position select External position 1.
5 Click on the associated [Assign] button.
6 Click on [Close].
Work position
1 Under Robotic arm position select External 1 and click on
[Start].
2 Move the lift downwards (button [Arrow down]) until the Polytron is
at the right height for rinsing.
If the Polytron does not fit in the middle of the washing station, then
the latter can be shifted laterally.
3 Click on [Configure rack].
4 Under Lift position select the Work position for External 1.
