2.12 Assembling and mounting the Polytron
®
drive
■■■■■■■■■■■■■■■■■■■■■■
30
■■■■■■■■
815 Robotic Soliprep for LC
2.12
Assembling and mounting the Polytron
®
drive
Please consult the Polytron user manual for details how to mount the aggre-
gate to the Polytron PT 1300 D.
Mounting the Polytron
1
2
Mount the Polytron as follows:
1 Insert the Polytron with the aggregate already mounted into the robotic
arm holder on tower 2 from above.
2 Readjust the position of the holder if necessary. Press down the fixing
lever of the holder to accomplish this.
2.13
Mounting the rinsing tubings for the Polytron
®
For rinsing the Polytron aggregate rinsing nozzles must be mounted on the
robotic arm. Proceed as follows:
