2.2 Installing MagIC Net ™ ￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
8 ￭￭￭￭￭￭￭￭ 815 Robotic Soliprep for LC
Note
The plug on the instrument end of the 6.2151.000 controller cable is
protected against accidental disconnection by means of a pull-out pro-
tection feature. If you wish to pull out the plug, you will first need to pull
back the outer plug sleeve marked with arrows.
Attaching the sample rack
1 Attach the sample rack in such a way that the two openings in the
bottom of the rack engage with the guide bolts on the turntable.
2 Tightly screw in the handle of the sample rack.
2.2 Installing MagIC Net
™
Installing MagIC Net
1 Insert the MagIC Net CD into the CD drive of the PC and carry out the
installation following the instructions. After this, start MagIC Net.
