Rockwell Automation 1203-USB USB Converter (Same as DRIVES-UM001) Out of synch with AB version. User Manual
Page 35
Troubleshooting
5-7
Type 0 Time Flt
The converter has not received a type 0 status
message within the specified time.
Use I/O Sent
The converter has begun sending drive-specific
control information.
Figure 5.3 – Example Parameter 03 Display im HyperTerminal
Table 5.8 – For MDI Drives
Code
Event
Description
F0
No Event
No event present in the event queue.
F1
Adapter Reset
The converter was reset by the user.
F2
Slave Detected
A slave was detected to be present by the
master.
F3
Slave Removed
A slave was detected to be removed by the
master.
F4
Host Timeout
A timeout condition on Msg to Host.
F5
Slave Timeout
A timeout condition on Msg to Slave.
F6
Master Timeout
A timeout condition on Msg to Master.
F7
Serial Timeout
A timeout on Serial 232 side (with control
enabled).
F8
Control Enabled
The converter has sent a “Soft Control
Enable” command to the drive.
F9
Control Disabled
The converter has sent a “Soft Control
Disable” command to the drive.
F10
EEPROM Sum Flt
Startup sequence detected corrupt
EEPROM storage in the converter.
Table 5.7 – For DPI Drives
Events
Description
Press the UP ARROW or DOWN ARROW key to scroll through the
parameter list. Press the LEFT ARROW or RIGHT ARROW key to
modify parameter values. Press the ENTER key to save a new
value.
1> Clr Event Queue = Enable
