2-4 USB Converter User Manual
2.5 Safety Precautions
Please read the following safety precautions carefully.
2.6 Quick Start
This section is provided to help experienced users quickly start using the 1203-USB
converter. If you are unsure how to complete a step, refer to the referenced chapter.
!
ATTENTION: Risk of injury or equipment damage exists. Only
personnel familiar with drive and power products and the associated
machinery should plan or implement the installation, start-up,
configuration, and subsequent maintenance of the product using the
converter. Failure to comply may result in injury and/or equipment
damage.
ATTENTION: Risk of injury or equipment damage exists. If the converter
is transmitting control I/O to the drive (indicated by a solid green diamond
LED), the drive may fault when you remove or reset the converter.
Determine how your drive will respond before removing or resetting a
connected converter.
Table 2.2 – Quick Start Steps
Step Action Refer to...
1 Review the safety precautions for the
converter. Throughout this manual
2 Install the converter.
DPI Drives: Connect a 20-OIM-H10 cable to
the 1203-USB converter and to the drive (see
Figure 2.2 ). Then, connect a USB cable to the
converter and to a computer. Make sure that
power has been applied to the drive.
MDI Drives: Connect a 22-OIM-H10 cable to
the 1203-USB converter and to the drive (see
Figure 2.3 ). Then, connect a USB cable to the
converter and to a computer. Make sure that
power has been applied to the drive.
Chapter 3, Installing the
Converter
3 Configure the converter for your application.
Use one of the following tools to configure
parameters in the 1203-USB converter:
• OIMs (only DPI and MPI drives)
• V*S Utilities (version 4.06 or higher)
• Terminal emulation software
Chapter 4, Configuring
the Converter
