Rockwell Automation 1440-ACNR XM ControlNet Adapter User Manual
Page 20
20
Publication ICM-UM001C-EN-E - March 2013
Chapter 2
Install the Adapter
4. Gently push the XM Bus connector into the side of the adapter to
complete the backplane.
5. Reinstall the XM module in the adjacent terminal base.
6. Connect the wiring to the adjacent terminal base.
7. Connect the ControlNet cable to the adapter.
Cont rolNet XM A
dapter
1440-ACNR
XM
®
MS
CHA
CHB
BPS
31768-M
