4 Dynamic Braking Kits for FlexPak 3000 and WebPak 3000 Digital DC Drives
DB Kit
Model Number
Contactor
Part Number
Resistor
Assembly
Part Number
Replacement
Resistor Part
Number
Number of
Resistors in
Assembly
Total
Ohms
912FK0010 705310-141A 800160-20P 48267-P 1 20.87
912FK0020 705310-141A 800160-20R
48267-J
1
1. Series connection
2 11.86
912FK0030 705310-141A 800160-20S
48267-H
1 2 9.39
912FK0050 705310-141A 800160-20T
48267-F
1 2 6.088
912FK0070 705310-141A 800160-20V
48267-D
1 2 3.824
912FK0100 705310-141A 800160-20W
48267-C
1 2 3.046
912FK0150 705310-141A 800160-20X
48267-A
1 2 1.932
912FK0200 705310-141A 800160-20Y
48267-C
2
2. Series/parallel connection consisting of two pairs of two resistors connected in series. The pairs of resistors are then connected in
parallel.
4 1.523
912FK0250 705310-141A 800160-20RB
48267-B
2 4 1.212
912FK0300 705310-141A 800160-20RC
48267-A
2 4 0.966
912FK0400 705310-150A 800160-20RD
402422-3F
1 2 0.998
912FK0500 705310-150A 800160-20RE
402422-3G
1 2 0.780
912FK0750 705310-160A 800160-20RF
402422-3K
1 2 0.498
912FK1000 705310-170A 800160-20RG
402422-3L
1 2 0.382
912FK1250 705310-180A 800160-20RH
402422-3P
1 3 0.372
912FK1500 705310-180A 800160-20RJ
402422-3Q 1 3 0.315
913FK0030 705310-141A 800160-20SP
48267-N
1 3 49.35
913FK0050 705310-141A 800160-20SR
48267-K
1 3 22.34
913FK0070 705310-141A 800160-20SS
48267-J
1 3 17.79
913FK0100 705310-141A 800160-20ST
48267-H
1 3 14.09
913FK0150 705310-141A 800160-20SV
48267-F
1 3 9.132
913FK0200 705310-141A 800160-20SW
48267-C
1 4 6.09
913FK0300 705310-141A 800160-20SX
48267-B 1 4 4.85
913FK0400 705310-141A 800160-20SY
48267-A
1 4 3.864
913FK0500 705310-141A 800160-20SB
402422-3D
1 3 3.00
913FK0750 705310-150A 800160-20SC
402422-3E
1 3 2.25
913FK1000 705310-150A 800160-20SD
402422-3F
1 3 1.497
913FK1500 705310-160A 800160-20SE
402422-3J
1 4 1.24
913FK2000 705310-170A 800160-20SF
402422-3K
1 4 0.996
913FK2500 705310-180A 802272-53R
402422-7Z 1 2 0.714
913FK3000 705310-180A 802272-53S
402422-7AD
1 2 0.644
913FK4000 — 802272-53T
402422-7AH
1 2 0.470
913FK5000 — 802272-53V
402422-7AL
1 2 0.412
913FK6000 — 802272-53W
402422-7AN
1 2 0.324
