Dynamic Braking Kits for FlexPak 3000 and WebPak 3000 Digital DC Drives 19
Technical Specifications
Contactor
Drive Horsepower /
Voltage Rating
Motor Armature
Amps / VDC VA Inrush VA Hold
705310-141A 1.5 HP @ 230 VAC 7 A / 240 VDC VA = 490 VA = 35
2 HP @ 230 VAC 9 A / 240 VDC
3 HP @ 230 VAC 12 A / 240 VDC
3 HP @ 460 VAC 6 A / 500 VDC
5 HP @ 460 VAC 10 A / 500 VDC
7.5 HP @ 460 VAC 14 A / 500 VDC
5 HP @ 230 VAC 20 A / 240 VDC
7.5 HP @ 230 VAC 29 A / 240 VDC
10 HP @ 460 VAC 19 A / 240 VDC
15 HP @ 460 VAC 27A / 240 VDC
10 HP @ 230 VAC 38 A / 240 VDC
15 HP @ 230 VAC 55 A / 240 VDC
20 HP @ 230 VAC 73 A / 240 VDC
25 HP @ 230 VAC 93 A / 240 VDC
30 HP @ 230 VAC 110 A / 240 VDC
20 HP @ 460 VAC 35 A / 500 VDC
25 HP @ 460 VAC 45 A / 500 VDC
30 HP @ 460 VAC 52 A / 500 VDC
40 HP @ 460 VAC 73 A / 500 VDC
50 HP @ 460 VAC 86 A / 500 VDC
60 HP @ 460 VAC 100 A / 500 VDC
705310-150A 40 HP @ 230 VAC 146 A / 240 VDC VA = 900 VA = 55
50 HP @ 230 VAC 180 A / 240 VDC
60 HP @ 230 VAC 218 A / 240 VDC
75 HP @ 460 VAC 129 A / 500 VDC
100 HP @ 460 VAC 167 A / 500 VDC
125 HP @ 460 VAC 207 A / 500 VDC
705310-160A 75 HP @ 230 VAC 265 A / 240 VDC VA = 900 VA = 55
150 HP @ 460 VAC 250 A / 500 VDC
705310-170A 100 HP @ 230 VAC 360 A / 240 VDC VA = 1200 VA = 70
200 HP @ 460 VAC 330 A / 500 VDC
705310-180A 125 HP @ 230 VAC 434 A / 240 VDC VA = 2900 VA = 105
150 HP @ 230 VAC 521 A / 240 VDC
250 HP @ 460 VAC 412 A / 500 VDC
300 HP @ 460 VAC 495 A / 500 VDC
