Rockwell Automation Publication IASIMP-QS035A-EN-P - December 2012 11
Chapter
1
Prepare the Kinetix 5500 Drive Hardware
In this chapter, you mount the Kinetix 5500 servo drive to your panel, make input power, motor, Ethernet, and
other connections at the drive, and configure the servo drive IP address for communication over the EtherNet/IP
network.
Before You Begin
Complete the prerequisite tasks related to the Logix5000 controller and Logix Designer application described in
the
Preface .
What You Need
This table lists the products you need to complete the tasks described in this chapter.
Refer to the Kinetix 5500 Servo Drives User Manual, publication 2198-UM001 , for more information on drive
installation and wiring.

Quantity Cat. No. Description
1 2198-Hxxx-ERS Kinetix 5500 servo drive
1
VPL-Axxxx or
VPL-Bxxxx
Kinetix VP Low-inertia servo motor
1 1606-XLxxx Bulletin 1606 24V DC power supply for control circuitry, digital inputs, safety, and motor brake
1 2090-CSxM1DF-xxAAxx
Bulletin 2090-CSBM1DF-xxAAxx single motor cable with SpeedTec DIN connector (brake conductors included)
Bulletin 2090-CSWM1DF-xxAAxx single motor cable with SpeedTec DIN connector (without brake conductors)
1 1585J-M8CBJM-x RJ45 to RJ45 patchcord Ethernet cables
3 Jumper wires for disabling the safety circuit
