Wiring the LDL-Series Linear Motor
Introduction
This section shows you how to wire your LDL-Series linear motor.
Connect the Linear Motor
Coil
Use the following procedure to connect your linear motor, catalog
number LDL-xxxxxxx-xHT11.
1. Using the Encoder Connector Kit, catalog number
LDC-ENC-CNCT, and the connector data on
, wire your
encoder to the connector.
2. Connect your encoder to the encoder connector on the Hall
effect module.
3. Attach the feedback and the power cables.
d. Align flats on each connector.
Topic
Page
Signal and Wire Definitions for Flying Lead Components
Making Your Own Extension Cables
Mounting and Wiring Two Identical Coils in Tandem
ATTENTION
Be sure that cables are installed and restrained to prevent
uneven tension or flexing at the cable connectors. Use Bulk
Head Connector Kit, catalog number LDC-BULK-HD, for
mounting these connectors.
Excessive and uneven lateral force at the cable connectors may
result in the connector’s environmental seal opening and
closing as the cable flexes.
Failure to observe these safety precautions could result in
damage to the motor and its components.
ATTENTION
Do not connect or disconnect the motor feedback cable or the
power cable while power. It may result in unexpected motion or
cause damage to the components.
