Publication LOGIX-UM004A-EN-P - March 2007

130 FuzzyDesigner Projects

3D Graph Control – Tool Bar

The tool bar (see 3D Graph Tool Bar) has nine buttons: Rotate Left,
Rotate Right, Rotate Up, Rotate Down, Rotate CCW, Rotate CW, Zoom
In, Zoom Out and Zoom To Fit Window. All of them have the
function identical to the menu items described previously.

3D Graph Tool Bar

3D Graph Control – Mouse Dragging

Drag the mouse to modify the 3D graph orientation. The graph is
rotated in the left-right or up-down direction if you hold the left
mouse button and drag horizontally or vertically. To rotate the graph
CW and CCW, press the SHIFT key, the left mouse button and drag
horizontally.
